c7222::FreeRtosCriticalSection Class Reference

Critical-section wrapper with destructor-based exit cleanup. More...

#include <freertos_critical_section.hpp>

Inheritance diagram for c7222::FreeRtosCriticalSection:

Collaboration diagram for c7222::FreeRtosCriticalSection:

Public Member Functions
	FreeRtosCriticalSection ()=default
	Construct a critical-section wrapper in the unlocked state.
	~FreeRtosCriticalSection ()
	Ensure the critical section is exited on destruction if entered.
void	Enter ()
	Enter the critical section (no-op if already entered by this object).
bool	Exit ()
	Exit the critical section.
bool	IsEntered () const
Public Member Functions inherited from c7222::NonCopyable
	NonCopyable (const NonCopyable &)=delete
NonCopyable &	operator= (const NonCopyable &)=delete
	NonCopyable (NonCopyable &&)=default
NonCopyable &	operator= (NonCopyable &&)=default
Public Member Functions inherited from c7222::NonMovable
	NonMovable (const NonMovable &)=default
NonMovable &	operator= (const NonMovable &)=default
	NonMovable (NonMovable &&)=delete
NonMovable &	operator= (NonMovable &&)=delete

Additional Inherited Members
Protected Member Functions inherited from c7222::NonCopyableNonMovable
	NonCopyableNonMovable ()=default
	~NonCopyableNonMovable ()=default
Protected Member Functions inherited from c7222::NonCopyable
	NonCopyable ()=default
	~NonCopyable ()=default
Protected Member Functions inherited from c7222::NonMovable
	NonMovable ()=default
	~NonMovable ()=default

Detailed Description

Critical-section wrapper with destructor-based exit cleanup.

This wrapper protects short non-blocking regions that must not be interrupted by context switches/interrupt handlers (platform dependent).

The object tracks a binary entered state (depth_ is 0 or 1). Calling Enter() while already entered is a no-op for this object, and destruction exits the critical section if it is still entered.

Typical usage:

c7222::FreeRtosCriticalSection cs;

cs.Enter();
// very short non-blocking critical region
(void)cs.Exit();

Constructor & Destructor Documentation

FreeRtosCriticalSection()

c7222::FreeRtosCriticalSection::FreeRtosCriticalSection ( )

default

Construct a critical-section wrapper in the unlocked state.

~FreeRtosCriticalSection()

c7222::FreeRtosCriticalSection::~FreeRtosCriticalSection

(

)

Ensure the critical section is exited on destruction if entered.

Member Function Documentation

Enter()

void c7222::FreeRtosCriticalSection::Enter

(

)

Enter the critical section (no-op if already entered by this object).

Exit()

bool c7222::FreeRtosCriticalSection::Exit

(

)

Exit the critical section.

Returns

false if not currently entered.

IsEntered()

bool c7222::FreeRtosCriticalSection::IsEntered

(

)

const

Returns

true if this object is currently entered.

---

The documentation for this class was generated from the following file:

• libs/elec_c7222/freertos_wrappers/include/freertos_critical_section.hpp
